Specifications:
(See all)
Adjust detector brightness
10 levels
Adjust detector contrast
10 levels
Adjust screen brightness
10 levels
Auto sleep
Adjustable shutdown time from 5 min, 10 min to 15 min
Automatic shutdown
Adjustable shutdown time from 15min, 30min to 60min
TrackIR series is Guide’s new launched handheld thermal imaging monocular designed for professional hunters which include 3 optional lenses (25mm/35mm/50mm). With 400x300 IR sensor and 1280x960 HD display, it provides adaptable and excellent thermal imaging in any conditions. Support smooth zoom, built-in stadiametric rangefinder, image quality adjustment, picture-in-picture functions. At a high frame rate of 50Hz, TrackIR captures sharp thermal imaging throughout dynamic and rapid motion in distance. It also supports connecting accessories to realize more functions.
Functions
Adjust detector brightness
10 levels
Adjust detector contrast
10 levels
Adjust screen brightness
10 levels
Auto sleep
Adjustable shutdown time from 5 min, 10 min to 15 min
Automatic shutdown
Adjustable shutdown time from 15min, 30min to 60min
Charging indicator switch
Available
Hot spot tracking
Available
Language settings
Chinese/English/Russian/German/French
Pseudo colors
White hot/black hot/ red hot/iron red/blue hot
Scene mode adjustment
Three modes: enhancement, sensed and natural
Wi-Fi1
Transmission of real-time video via WiFi for remote control, 2.4G frequency band, distance up to 15m
Work indicator switch
Switch
Smooth zoom in
Available
Image enhancement
Available
Super power saving mode
Available
Available
Video recording
Available
Compensation mode
Automatic compensation, shutter compensation and scene compensation
Rough ranging
Available
Infrared detector
NETD
≤50mk @ F1 25℃
Wavelength range
8～14μm
Resolution ratio
400×300
Lens
Field angle
11,1×8,3
Focusing mode
Manual focusing
Focal length
35 mm F1.2
Frame rate
Output frame frequenc
50Hz
Zoom multiple
Digital zoom multiple
1x—4x
Optical zoom multiple
2,3x
Visual effect
It's like viewing at a 22’‘ screen at a distance of 1m
Power supply
Battery
Built-in 2*18650 batteries with a capacity of 6,000mah
Working time
Battery continuous working time ≥ 5 hours @ 25 ℃ (only observe the state)
Interface
External extension
External display and external Bluetooth remote control
Mechanical interface
1/4'' tripod base port
USB
Type C (USB 2.0 standard) interface, chargeable and data access
Video interface
Micro HDMI
Wifi
Transmission of real-time video via WiFi, 2.4G frequency, distance up to 15m
Display screen
Eyepiece
Monocular, exit pupil distance ≥ 10mm, adjustable diopter -4~＋2
Eyepiece zoom multiple
13,8x
Resolution ratio1
1280*960
Video output system
HDMI
Display screen
0.4'', color LCOS screen
Button
Butt
Switch/Up/menu/Down/Photo/video
System
Pip
Capable to swipe left and up, or pause in the middle and swipe up; or swipe right and up to close
Startup time
15s (turn on to live image) @25℃
Time setting
Available
Watermark settings
Closure, and setting of date or date and location
Restore to default
Available
Memory capacit
16GB
